Instruction

YL-120 Automatic Cartoning Machine is an efficient and automated cartoning equipment, suitable for automated production lines of various products, such as food, pharmaceutical, chemical and other industries. The automatic cartoning machine can automatically put products into boxes and perform operations such as sealing and labeling.

Main technical parameters

Encasing speed		30-90 boxes/min
Box	Quality requirement	250-350g/m2
	Dimension rangeL×W×H	(65-125)mm×(35-85)mm×(13-50)mm
	Quality requirement	60-70g/m2
Compressed air	Working pressure	≥0.6mpa
	Air consumption	120-160L/min
Power		220V/50Hz
Motor power		0.75kw
Machine dimension(L×W×H)		2700mm×1140mm×1800mm
Machine weight		1200kg

Sample Picture

Feature

1.International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.

2.Adopt human-machine operation system.

3.Automatically displaying device for trouble, speed and finished products counting.

4.Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.

5.No products not suction leaflet, no leaflet not suction carton .

6.Automatic detection and rejection device for lacking blister goods and leaflets.

7.Protecting automatically for overloading.

8.stable performance , operation is easy.

When choosing an automatic cartoning machine manufacturer, you need to consider: product quality, production capacity, technical support and price.
