Instruction

YL-450 Cling Film Cartoning Machine is suitable for cling film, film roller, preservative film, plastic wrap, cling wrap into carton and sealing carton by tuck-in or with glue .The machine finished running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. It includes cantons opening and forming, products insert into carton, printing batch number, sealing or option hot-glue device. The machine can be single used or linked with VFFS Machine, Shrink Machine, Overwrapping Machine and pillow packing machine to form a production line.

Main technical parameters

Encasing speed		20-30boxes/min
Box	Quality requirement	250-450g/m2
	Dimension range(L×W×H)	(100-350)mm×(100-250)mm×(20-100)mm
Compressed air	Working pressure	≥0.6mpa
	Air consumption	20m3/h
Power		380V/50Hz
Motor power		1.5kw
Machine dimension(L×W×H)		4200mm×1350mm×1900mm
Machine weight		1600kg
