Encasing speed: 30-60boxes/min
Working pressure: ≥0.6mpa
Air consumption: 20m3/h
Power: 380V/50Hz
Motor power: 1.5kw
Machine weight: 1600kg
YL-60 Mask Cartoning Machine is suitable for mask ,facial mask, wet mask into carton and sealing carton by tuck-in or with glue. The machine finished running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. It includes cantons opening and forming, products insert into carton, printing batch number, sealing or option hot-glue device. The machine can be single used or linked with VFFS Machine, Shrink Machine, Overwrapping Machine and pillow packing machine to form a production line.
Encasing speed |
30-60boxes/min |
|
Box |
Quality requirement |
250-350g/m2 |
Dimension range(L×W×H) |
(70-250)mm×(80-180)mm×(20-90)mm |
|
Compressed air |
Working pressure |
≥0.6mpa |
Air consumption |
20m3/h |
|
Power |
380V/50Hz |
|
Motor power |
1.5kw |
|
Machine dimension(L×W×H) |
3800mm×1350mm×1900mm |
|
Machine weight |
1600kg |
The manufacturer of the facial mask cartoning machine introduces the precautions for using the facial mask cartoning machine to help you easily extend the life of the equipment.
Standardize operations and ensure safety
1. Operation training: Before operating the mask cartoning machine, the operator should receive professional training and be familiar with the equipment structure, performance, and operating procedures.
2. Safety inspection: Before each use, a comprehensive safety inspection of the equipment should be carried out to ensure that all components are intact and to avoid safety hazards.
3. Standardized operation: During the operation, the operating procedures should be strictly followed. It is prohibited to disassemble or adjust equipment parts at will.
Maintenance and performance improvement
1. Daily cleaning: After use every day, the equipment should be cleaned inside and outside to remove residues and keep the equipment clean and tidy.
2. Regular maintenance: Carry out regular maintenance on the equipment according to the maintenance cycle recommended by the manufacturer, such as replacing worn parts, lubricating parts, etc.
3. Maintenance records: record the maintenance status of the equipment in detail to provide a basis for future troubleshooting and equipment improvement.
1.International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.
2.Adopt human-machine operation system.
3.Automatically displaying device for trouble, speed and finished products counting.
4.Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons
5.No products no suction carton
6.Automatic detection and rejection device for lacking product.
7.Protecting automatically for overloading.
8.stable performance operation is easy.
