Automatic Tube Cartoner-Shinking Machine

Instruction

Automatic Tube Cartoner-Shinking Machine is suitable for pharmaceuticals product into carton, such as tube/ointment into carton. The machine finished running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. It includes 1to 4folds leaflet automatic folding, cantons in suction and forming, products and leaflet insert into carton, printing batch number, sealing or option hot-glue device. The machine can be single used or linked with label machine, tube sealing and filling Machine, blister packing machine, shrink machine, overwrapping machine, bundling machine and case packer to form a production line.

Feature

1.International famous brand of electrical component such as PLC touch screen,frequency inverters, etc.

2.Adopt human-machine operation system.

3.Automatically displaying device for trouble, speed and finished products counting.

4.Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.

5.No products not suction leaflet, no leaflet not suction carton .

6.Automatic detection and rejection device for lacking blister goods and leaflets.

7.Protecting automatically for overloading.

8.stable performance , operation is easy.

Main Technical Parameters

Machine Picture

2. LY-500 Automatic Sleeve sealing and shrink packing machine

Instruction

This machine is a fully automatic shrink packaging machine including sleeve sealer and shrink tunnel which can feed products, collating, seal and cut film and shrink film bag automatically. it is widely used in food, pharmaceutical, cosmetics, printing, hardware, and other industry. This machine can collate bottles (round or square), cans, gable cartons, and tetra cartons automatically. it can connect filling machine or labelling machine to make production line unmanned.

Feature

1.Bottles can be collated faster by a special faster and stable collating device and never fall down.

2.Adopt durable “u” shape alloyed sealing knife and saw teeth cutting knife with anti-stick teflon coats supported by four columns, the sealing line is very strong and can use thicker pe film for heavy products.

3. Rows can be set on the touch screen. when product size changes only adjust packing size on the machine within a short time without changing any molds.

4.Adopt siemens plc and colorful touch screen, omron temperature controller, timer, relay, switch, and sensor.

5.Optional output roller table or conveyors are available.

6.Optional safety cover is available.

Main technical parameters

Sample Picture
